Sliding Doors

  • Allows maximum amount of light into your room
  • Effortlessly slides both sides to accommodate to room changes
  • Sleek, durable, aluminum design
  • Advance engineering allows for great energy efficiency
  • Flush installation giving a great indoor outdoor flow
  • Currently available in 20mm Cortizo , 25mm, Reynaers 34mm and also 47mm frames

Fact file

20mm Sliding Door 25mm Sliding Door 34mm Sliding Door 47mm Sliding Door Bifold Door
Sightline 20mm 25mm 34mm 47mm 120mm
Threshold Flush Flush with Concealed Track 13mm Lip Flush Flush
U Value From 1.3 From 0.9 From 1.6 From 1.1 From 1.1U
Maximum thickness of glass 30mm 54mm 30mm 34mm 45mm
Triple Glazing? Not Available Yes Available Not Available Yes Available Yes Available
Air Permeability Air tightness up to Class 4 Air tightness up to Class 4
Water Tightness Water resistance to 600Pa/Class 9A
Wind Resistance Wind resistance to Class A3
Standard Colours Anthracite Grey / Black / White Anthracite Grey / Black / White Anthracite Grey / Black / White Anthracite Grey / Black / White Anthracite Grey / Black / White
Colours Any RAL and Dual Colour Any RAL and Dual Colour Any RAL and Dual Colour Any RAL and Dual Colour Any RAL and Dual Colour
Outer frame thickness 44mm 57mm 68mm 47mm 55mm
Max Number of Sashes 6 6 6 6 14
Max width/height per sash 2500mm Width x 3000mm Height 4000mm Width x 4000mm Height 2500mm Width x 2500mm Height 2500mm Width x 3000mm Height 1200mm Width x 3000mm Height
Max weight per sash 320kg 720kg 160kg 280kg 120kg
PAS24? Yes Available on request Yes Available on request Not Available Yes Available on request Yes Available on request
Guarantee 10 Year Guarantee 10 Year Guarantee 5 Year Guarantee 10 Year Guarantee 10 Year Guarantee
